Anzugsbolzen JIS B 6339(MAS 403 BT)

BESTELLUNG NR.	d	D	M	L	d1	h	I	α	O
305.20.45	7	11	M12	43	-	18	20	45°	-
305.20.60	7	11	M12	43	-	18	20	60°	-
305.20.90	7	11	M12	43	-	18	20	90°	-
306.20.45.IK	8	11	M12	43	2,5	18	20	45°	X
405.20.45	10	15	M16	60	-	28	25	45°	X
405.20.60	10	15	M16	60	-	28	25	60°	X
405.20.90	10	15	M16	60	-	28	25	90°	X
405.20.45.1	10	15	M16	57	-	25	25	45°	X
406.20.45.IK	10	15	M16	60	3	28	25	45°	X
406.20.60.IK	10	15	M16	60	3	28	25	60°	X
406.20.90.IK	10	15	M16	60	3	28	25	90°	X
406.20.45.1.IK	10	15	M16	57	3	25	25	45°	X
505.20.45	17	23	M24	85	-	35	40	45°	X
505.20.60	17	23	M24	85	-	35	40	60°	X
505.20.90	17	23	M24	85	-	35	40	90°	X
506.20.45.IK	17	23	M24	85	6	35	40	45°	X
506.20.60.IK	17	23	M24	85	6	35	40	60°	X
506.20.90.IK	17	23	M24	85	6	35	40	90°	X

Zubehör
